USB socket “Slim”
USB socket with a slim size of 13.5 mm and a simple appearance.
Suitable for handlebars with 22.2 and 25.4 mm.
- USB 1 port (max.5V2.4A)
- Input voltage: DC12V
- Input voltage range: DC10V-16V
- Stand-by current (without load): 0.6 mA
- Output voltage: 4.8-5.2 V
- Nominal output current: 2.4A
It is a simple waterproofness for eg rain. Do not point a pressure washer or the like at the unit.
The standby power consumption is high due to the high output specification. To prevent the battery from draining, please turn off the power supply when the vehicle is stopped, e.g. B. a connection with the master key or a separate switch.
